Husky Frameless Onion Water Tank

The Husky self-supporting frameless foldable and collapsible portable onion water tanks are designed for fire fighters for use as a dump tank in water shuttle operations.

Also referred to as pumpkin water tanks, these portable water tanks are the perfect solution when storage and manpower are a concern.

With a frameless design, there is no assembly required. The onion tanks can be setup with a single person. The tanks are easy to transport and store. They are also designed to work better on slopes than other open tank on the market.

Husky Self Supporting Water Tanks include Husky's patented Easy Lift Handles, making the Husky tank the easiest to use water tank on the market.

Choose the following Types:

• Low Side: lower height design w/ max filled water height of 28 to 33 inches.
• High Side: higher height design w/ max filled water height of 40 to 60 inches.

*High Side sizes from 6,000 to 20,000 gallons offer max filled water height ranging from 60 inches to 72 inches.

Choose the following Liner Material:

• 22 on Vinyl
• 22 oz Exlon
• 40 oz Vinyl (available for 6,000 to 20,000 gallon sizes)

Vinyl liner is the standard option and Exlon liner is a high performance liner.

Exlon liner is an ethylene interpolymer alloy designed for UV resistance, heat resistance, abrasion, puncture resistance, and excellent cold cracking quality.

The frameless onion water tanks can be quickly deployed and filled by one person. The heavy duty foam collar will rise as the water level increases.

Applications:

• Fire Fighting.
• Water relay.
• Water storage.
• Mixing tank (fire retardant).
• Hazardous waste.

Features:

• Easy setup. No assembly; just unfold and go.
• No framework means less weight with the same capacity and allows for easier storage.
• Self-rising sidewalls.
• Great for oil spill clean-up, chemical or fuel storage, potable or wastewater storage.
• Chemical & fuel resistant materials. Potable NSF 61 approved materials.
• Exlon or Vinyl Liners.
• Easy Lift Handles.
• Unique Flotation Collar.
• 5 colors (red, yellow, orange, black).

Available Sizes & Dimensions (Filled Height x Top Diameter x Base Diameter):

Low Side Specs:

• 250 gallons: 28" high x 3'7" top diameter x 5'10" base - 27 pounds
• 500 gallons: 33" high x 4'10" top diameter x 7'0" base - 39 pounds
• 1,000 gallons: 33" high x 6'11" top diameter x 9'5" base - 54 pounds
• 1,500 gallons: 33" high x 8'8" top diameter x 11'8" base - 67 pounds
• 2,000 gallons: 33" high x 10'0" top diameter x 13'0" base - 75 pounds
• 2,500 gallons: 33" high x 11'2" top diameter x 14'4" base - 84 pounds
• 3,000 gallons: 33" high x 12'3" top diameter x 15'8" base - 99 pounds
• 3,500 gallons: 33" high x 13'2" top diameter x 17'0" base - 105 pounds
• 4,000 gallons: 33" high x 14'2" top diameter x 18'0" base - 114 pounds
• 5,000 gallons: 33" high x 15'10" top diameter x 19'8" base - 125 pounds
• 6,000 gallons: 33" high x 17'8" top diameter x 21'6" base - 143 pounds*
• 10,000 gallons: 33" high x 22'11" top diameter x 26'9" base - 200 pounds*

*only available in 40 ounce vinyl liner.

High Side Specs:

• 500 gallons: 40" high x 4'0" top diameter x 6'9" base - 39 pounds
• 1,000 gallons: 44" high x 5'6" top diameter x 8'6" base - 54 pounds
• 1,200 gallons: 44" high x 5'10" top diameter x 9'8" base - 59 pounds
• 1,600 gallons: 44" high x 6'10" top diameter x 10'8" base - 67 pounds
• 1,800 gallons: 46" high x 7'3" top diameter x 11'0" base - 72 pounds
• 2,000 gallons: 48" high x 7'9" top diameter x 11'9" base - 75 pounds
• 2,500 gallons: 48" high x 8'6" top diameter x 12'8" base - 84 pounds
• 3,000 gallons: 48" high x 9'2" top diameter x 14'2" base - 99 pounds
• 4,000 gallons: 48" high x 11'0" top diameter x 16'2" base - 114 pounds
• 5,000 gallons: 60" high x 10'6" top diameter x 16'2" base - 125 pounds
• 6,000 gallons: 60" high x 11'8" top diameter x 17'4" base - 172 pounds*
• 8,000 gallons: 70" high x 12'0" top diameter x 18'0" base - 230 pounds*
• 10,000 gallons: 72" high x 13'6" top diameter x 20'6" base - 299 pounds*
• 14,000 gallons: 72" high x 16'9" top diameter x 23'9" base - 368 pounds*
• 20,000 gallons: 72" high x 20'9" top diameter x 27'9" base - 499 pounds*

Liner Material Colors

• 22 ounce Vinyl (red, yellow, blue, orange, green, white, black, lime green)*.
• 22 ounce Exlon (red & yellow).

• 40 ounce Vinyl (red & yellow).

*22 ounce vinyl comes a 28 ounce floor liner.
